Name: Kẹp cảm biến / bộ điều hợp 8115
SKU: K8115
Rating: 5 (1 reviews)

Kẹp cảm biến / bộ điều hợp 8115

Mã SP:K8115

|Tình trạng: Còn hàng

Giá: 5,096,550VND0%

Thương hiệu: kyoritsu
Nước sản xuất: Japan

Số lượng:

Thêm giỏ hàng Mua ngay

Thông tin sản phẩm

Permits extension of the AC and DC current ranges of almost any Digital Multimeters (DMMs) without breaking the circuit under test.
• Using KEW 8115 with KEW 1051/1052 (DMM) the display can be set for direct reading in A.

Measuring range	AC 0.1 - 130Arms (185Apeak)	DC 0 - ±180A
Output voltage	AC 10mV/A	DC 10mV/A
Accuracy	±1.2%rdg±0.4mV (50/60Hz) ±2.5%rdg±0.4mV (40 - 1kHz)	±1.2%rdg±0.4mV (*)
Low battery warning	2.2V±0.2V or less - Red LED flash (1.9V±0.2V - Automatically power off)
Conductor size	Max. Ø12mm
Withstand voltage	AC 3540V (RMS 50/60Hz) for 5 sec.
Operating temperature & humidity range	-10 to 55ºC, relative humidity 85% or less (no condensation)
Output impedance	Approx. 10Ω or less
Applicable standards	IEC 61010-1 CAT III 300V Pollution degree 2, IEC 61010-2-032, IEC 61326-1
Power source	DC3V (size AAA alkaline battery LR03×2pcs) * Continuous use: approx. 40 hours (Auto power off: approx. 20 minutes)
Cord length	Approx. 1,200mm
Output connector	Φ4mm banana plug
Dimensions	127(L)×42(W)×22(D) mm
Weight	Approx. 140g
Accessories	Soft case, LR03×2, Instruction manual
